Features
Maximum data transfer rate (5 GHz): 867 Mbit/s
Maximum data transfer rate: 1200 Mbit/s
Ethernet LAN data rates: 1000 Mbit/s
2.4 GHz: Yes
MIMO: Yes
Quality of Service (QoS) support: Yes
Networking standards: IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11b, IEEE 802.3af, IEEE 802.11a
5 GHz: Yes
Transmitting power (CE): 20 - 23 dBm
Transmitting power (FCC): 21 - 21 dBm
Number of users: 200 user(s)
VLAN support: Yes
MIMO type: Multi User MIMO
Airtime Fairness (ATF): Yes
Maximum data transfer rate (2.4 GHz): 300 Mbit/s
BeamForming: Yes
Wireless isolation: Yes
Coverage area: 25 m²
6 GHz: No
Design
LED indicators: Yes
Placement: Wall
Product colour: White
Reset button: Yes
Power
Power over Ethernet (PoE): Yes
Power consumption (max): 24.4 W
Power over Ethernet (PoE) type supported: Passive PoE, Active PoE
Security
Security algorithms: WPA-Personal, SNMPv3, SSH, WPA-Enterprise, WPA2-Personal, WPA2-Enterprise, SNMPv2
MAC address filtering: Yes
Service Set Identifier (SSID) features: Multiple SSIDs, SSID broadcast
Remote Authentication Dial-In User Service (RADIUS): Yes
Guest access: Yes
Number of SSID supported: 16
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Management features
Firmware upgradeable: Yes
Web-based management: Yes
Syslog: Yes
Weight & dimensions
Weight: 212 g
Depth: 86 mm
Height: 20 mm
Width: 143 mm
Packaging content
Quantity per pack: 1 pc(s)
Quick start guide: Yes
Mounting kit: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE
Ports & interfaces
Ethernet LAN (RJ-45) ports: 4
Antenna
Antenna gain level (max): 4 dBi
Antenna type: Internal
