TP-Link InSight S345S Bullet IP security camera Outdoor 2688 x 1520 pixels Ceiling /Wall /Pole

Design
Form factor: Bullet
Product colour: White
International Protection (IP) code: IP67
Mounting type: Ceiling/Wall/Pole
Housing material: Metal

Power
Power source type: DC, PoE
DC output voltage: 12

Security
Active tampering alarm: Yes
Video motion detection: Yes
Password protection: Yes
Intelligent Video Surveillance (IVS) system features: Line crossing detection, Vehicle detection, Region entrance detection, Region exiting detection, Abandoned object, Abnormal sound detection, Scene change, Intrusion, Human detection
IP address filtering: Yes
HTTPS encryption: Yes
Alarm input channels: 1
Alarm output channels: 1
Digest authentication: Yes

Operational conditions
Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%

Management features
Cloud-managed: Yes
Web browser: Yes

Weight & dimensions
Weight: 600 g
Length: 191 mm
Diameter: 6.6 cm

Network
Bluetooth: No
Ethernet interface type: Fast Ethernet
Wi-Fi: No
Ethernet LAN: Yes
Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP

Performance
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Infrared (IR) cut-off filter: Yes
Dynamic range: 120 dB
Alarm input/output: Yes
Placement supported: Outdoor

Packaging content
Number of cameras: 1
Mounting kit: Yes
Manual: Yes

Audio
Built-in speaker(s): Yes
Audio system: 2-way
Built-in microphone: Yes
Signal-to-Noise Ratio (SNR): 52 dB

Storage
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
Maximum memory card size: 512 GB
Built-in HDD: No

Ports & interfaces
Ethernet LAN (RJ-45) ports: 1

Camera
Tilt angle range: 0 - 75°
Angle of rotation: 360°
Camera shutter speed: 1/3 - 1/10000 s
Minimum illumination: 0.0005 lx
Pan range: 0 - 360°
Lens viewing angle, diagonal: 115°
Lens viewing angle, horizontal: 95°
Lens viewing angle, vertical: 51°

Image sensor
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 1.79 mm (1 / 1.79")

Video
Bit rate: Main Stream: 256 Kbps - 6 Mbps; Sub-Stream: 64 Kbps - 1024 Kbps
Maximum resolution: 2688 x 1520 pixels
Supported graphics resolutions: 320 x 240, 640 x 360, 640 x 480 (VGA), 2048 x 1280, 704 x 576, 352 x 288, 2688 x 1520, 848 x 480, 2560 x 1440, 1280 x 720 (HD 720), 2304 x 1296, 1920 x 1080 (HD 1080)
Smart IR: Yes
Total megapixels: 4 MP
Region of Interest (ROI) encoding: Yes
Video streaming: Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Highlight Compensation (HLC): Yes
Noise reduction: Yes
Video compression formats: H.264+, H.265+, H.264, H.265
Back Light Compensation (BLC): Yes
Noise reduction technology: 3D noise reduction

Night vision
Infra-red wavelength: 850 nm
Night vision distance: 30 m
Night vision: Yes
Number of illumination LEDs: 2
LED type: IR/White

Lens system
Number of lenses: 1
Identify distance: 7 m
Recognize distance: 14 m
Fixed focal length: 4 mm
Maximum aperture number: 1
Observe distance: 29 m
Detect distance: 76 m

Sustainability
Compliance certificates: BSMI, KC, VCCI, Industry Canada (IC), Federal Communications Commission (FCC), CE
