TP-Link INSIGHT S455 Turret IP security camera Outdoor 2880 x 1620 pixels Ceiling

Design
Product colour: White
International Protection (IP) code: IP67
Form factor: Turret
Protection features: Waterproof
Housing material: Metal
Weatherproof: Yes
Mounting type: Ceiling

Power
Power consumption (max): 11 W
Power source type: DC, PoE
DC output voltage: 12
Power consumption (Power over Ethernet (PoE)): 12 W

Security
Built-in siren: Yes
Alert notification type: Push notification
Video motion detection: Yes
Mirror: Yes
IP address filtering: Yes
Motion sensor: Yes
Password protection: Yes
HTTPS encryption: Yes

Operational conditions
Operating temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 60 °C

Management features
Reset button: Yes
Web-based management: Yes
Web browser: Yes
Cloud-managed: Yes

Weight & dimensions
Weight: 480 g
Length: 111 mm
Height: 83.7 mm
Width: 111 mm

Network
Networking standards: IEEE 802.3at, IEEE 802.3af
Bluetooth: No
Wi-Fi: No
Ethernet LAN: Yes
Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Live view: Yes

Performance
Connectivity technology: Wired
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Dynamic range: 120 dB
Remote viewing: Yes
Maximum operating distance: 64 m
Placement supported: Outdoor
Day/night mode: Yes
Infrared (IR) cut-off filter: Yes

Packaging data
Package type: Box

Packaging content
Mounting kit: Yes
Number of cameras: 1
Manual: Yes
Drilling template included: Yes
Screws included: Yes

Audio
Built-in microphone: Yes
Audio system: 2-way
Audio output channels: 1.0 channels
Built-in speaker(s): Yes
Sample rate: 8 kHz
Number of microphones: 1
Audio input channels: 1.0 channels
Bit rate range: 0 - 64 Kbit/s
Audio formats supported: G.711 A-law

Storage
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 512 GB

Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1

Camera
Tilt angle range: 0 - 90°
Minimum illumination: 0 lx
Lens viewing angle, vertical: 58.8°
Camera shutter speed: 1/3 to 1/10000
Lens viewing angle, horizontal: 111.4°
Lens viewing angle, diagonal: 134°

Image sensor
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Sensor type: CMOS
Progressive scan: Yes

Video
Maximum resolution: 2880 x 1620 pixels
Bit rate: Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 64 Kbps to 512 Kbps
Supported graphics resolutions: 2880 x 1620, 2304 x 1296, 2048 x 1280, 2688 x 1520, 1920 x 1080 (HD 1080)
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Image quality adjustment: Sharpness, Brightness, Contrast, Mirror, Saturation
Digital Wide Dynamic Range (DWDR): Yes
Video recording: Yes
Video compression formats: H.265+, H.264+, H.265, H.264
Total megapixels: 5 MP
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Night vision
LED type: IR/White
Night vision: Yes

Lens system
Recognize distance: 13 m
Observe distance: 27 m
Maximum aperture number: 1.6
Fixed focal length: 2.8 mm
Identify distance: 6 m
Detect distance: 64 m
Fixed focus: Yes
