TP-Link IP Camera InSight S245(2 8mm)

Design
Mounting type: Ceiling
Weatherproof: Yes
Form factor: Dome
IK code: IK10
Housing material: Metal
Protection features: Waterproof
Product colour: White
International Protection (IP) code: IP67

Power
DC output voltage: 12
Power consumption (Power over Ethernet (PoE)): 12.52 W
Power source type: DC, PoE

Security
IP address filtering: Yes
Password protection: Yes
Video motion detection: Yes
Detection distance: 64 m
Digest authentication: Yes
Intelligent Video Surveillance (IVS) system features: Line crossing detection, Intrusion, Crossing line, Vehicle detection, Region entrance detection, Human detection, Moving object, Scene change, Abnormal sound detection, Region exiting detection
Motion sensor: Yes
HTTPS encryption: Yes
Mirror: Yes
Human and vehicle targets classification: Yes
Built-in siren: Yes
Alert notification type: Push notification

Operational conditions
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%

Management features
Web browser: Yes
Cloud-managed: Yes
Web-based management: Yes
Reset button: Yes

Weight & dimensions
Height: 89 mm
Width: 122 mm
Depth: 122 mm
Weight: 620 g

Network
Live view: Yes
Networking standards: IEEE 802.3af, IEEE 802.3at
Ethernet LAN: Yes
Bluetooth: No
Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Wi-Fi: No

Performance
Remote viewing: Yes
Placement supported: Outdoor
Infrared (IR) cut-off filter: Yes
Day/night mode: Yes
Dynamic range: 120 dB
Maximum operating distance: 64 m
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Connectivity technology: Wired

Packaging content
Number of cameras: 1
Manual: Yes

Audio
Number of microphones: 1
Built-in speaker(s): Yes
Bit rate range: 0 - 64 Kbit/s
Sample rate: 8 kHz
Audio formats supported: G.711 A-law
Audio output channels: 1.0 channels
Audio system: 2-way
Built-in microphone: Yes
Audio input channels: 1.0 channels

Storage
Maximum memory card size: 512 GB
Compatible memory cards: MicroSD (TransFlash)

Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1

Camera
Lens viewing angle, horizontal: 110°
Lens viewing angle, vertical: 58.1°
Lens viewing angle, diagonal: 133.5°
Camera tilt control: Yes
Camera pan control: Yes
Camera shutter speed: 1/3 to 1/10000
Minimum illumination: 0 lx
Tilt angle range: 0 - 75°

Image sensor
Sensor type: CMOS
Progressive scan: Yes
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")

Video
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Image quality adjustment: Contrast, Mirror, Saturation, Sharpness, Brightness
Video compression formats: H.265+, H.264, H.264+, H.265
Video recording: Yes
Supported graphics resolutions: 2560 x 1440, 2688 x 1520, 2048 x 1280, 2304 x 1296, 1920 x 1080 (HD 1080), 1280 x 720 (HD 720)
Digital Wide Dynamic Range (DWDR): Yes
Total megapixels: 4 MP
Bit rate: Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264
Maximum resolution: 2688 x 1520 pixels
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes

Night vision
Night vision: Yes
LED type: IR/White

Lens system
Observe distance: 27 m
Fixed focal length: 2.8 mm
Identify distance: 6 m
Detect distance: 64 m
Recognize distance: 13 m
Maximum aperture number: 1.6
