Design
Reset button: Yes
Wall mountable: Yes
Product colour: Black
Housing material: Metal
LED indicators: Power, Link, Activity
Power
Power supply included: Yes
Power consumption (max): 3.92 W
Power source: DC
DC input voltage: 5 V
Input current: 0.6 A
Security
IGMP snooping: Yes
Loop protection: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Heat dissipation: 13.37 BTU/h
Management features
Quality of Service (QoS) support: Yes
Switch type: Unmanaged
Weight & dimensions
Height: 25 mm
Depth: 101 mm
Width: 158 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.3ab, IEEE 802.1p, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
10G support: No
Flow control support: Yes
Performance
Fanless: Yes
Packaging content
Cables included: Power
User guide: Yes
Certificates
Compliance certificates: EAC, RoHS, CE, Federal Communications Commission (FCC), UKCA
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports quantity: 8
Data transmission
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 16
MAC address table: 4000 entries
Forwarding rate: 11.9 Mpps
Switching capacity: 16 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
