Certification: CE, FCC
Design
On/off switch: Yes
Product colour: White
Reset button: Yes
LED indicators: Yes
Power
Power consumption (max): 9 W
Operational conditions
Operating temperature (T-T): 0 - 30 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
Width: 76.4 mm
Depth: 66.5 mm
Height: 163 mm
Network
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11a, 802.11g, Wi-Fi 4 (802.11n), 802.11b
SSID Broadcast: Yes
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi: Yes
Networking standards: IEEE 802.3, IEEE 802.11a, IEEE 802.3ab, IEEE 802.3u, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.11b
Security algorithms: 64-bit WEP, 128-bit WEP, WPA-PSK, WPS, WPA2-PSK
Web-based management: Yes
Wi-Fi data rate (max): 1750 Mbit/s
Performance
Windows operating systems supported: Yes
Type: Network transmitter
Data transfer rate: 1750 Mbit/s
Linux operating systems supported: Yes
WPS push button: Yes
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Mac operating systems supported: Yes
Packaging data
Package height: 86 mm
Package width: 202 mm
Package depth: 125 mm
Packaging content
Cables included: LAN (RJ-45)
Quick start guide: Yes
Certificates
Compliance certificates: RoHS
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Antenna
Antennas quantity: 3
Antenna type: External
Logistics data
Harmonized System (HS) code: 85176990
