HARDWARE FEATURES
Processor
Qualcomm CPU
Interface
2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit
Button
1 Reset button on the underside
External Power Supply
12 V/1.2 A
Dimensions
Φ3.6 in. x 7.5 in. (Φ90.7 mm x 190 mm)
Antenna Type
2 internal dual-band antennas per Deco unit
WIRELESS FEATURES
Wireless Standards
IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz
Frequency
2.4 GHz and 5 GHz
Signal Rate
300 Mbps on 2.4 GHz
867 Mbps on 5 GHz
Transmit Power
FCC: <30 dBm
CE: <20 dBm (2.4 GHz)
<23 dBm (5 GHz)
Wireless Security
WPA-PSK/WPA2-PSK
Advanced Functions
● Router/Access Point Mode
● Optional Ethernet Backhaul
● Guest network
● TP-Link Mesh Technology:
MU-MIMO
Auto Path Selection
Self-Healing
AP Steering
Band Steering
Beamforming
SOFTWARE FEATURES
Quality of Service
WMM
IPv6
Support
WAN Type
Dynamic IP/Static IP/PPPoE/L2TP/PPTP
Management
Local Management, Remote Management
DHCP
Server, Client
Port Forwarding
Support
Access Control
Blacklist
Firewall Security
SPI Firewall
Protocols
Supports IPv4 and IPv6
Advanced Features
Parental Controls
Quality of Service
Advanced Functions
Monthly Reports
Auto FW Update
Expand Wi-Fi by adding more Deco units
Guest Network
2.4 GHz guest network x 1
5 GHz guest network x 1
Beamforming
Support
APP
Easy setup via Deco App
POWER
AC adapter input
100-240V ~ 50/60Hz 0.4A
AC adapter output
12V ⎓ 1.2A
