Certification: FCC, CE
Design
Internal: Yes
Product colour: Grey, Green
LED indicators: Yes
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Height: 63 mm
Depth: 18 mm
Weight: 62 g
Width: 84 mm
Network
Ethernet LAN data rates: 100, 10, 10000 Mbit/s, 1000 Mbit/s
Maximum data transfer rate: 10000 Mbit/s
Networking standards: IEEE 802.3ab, IEEE 802.3ad, IEEE 802.1Q, IEEE 802.3u, IEEE 802.3an
Ethernet LAN: Yes
Ethernet interface type: 10 Gigabit Ethernet
Copper ethernet cabling technology: 10GBASE-T, 10BASE-T, 100BASE-TX, 1000BASE-T
Jumbo frames support: Yes
Jumbo frames: 16000
VLAN tagging: Yes
System requirements
Windows operating systems supported: Yes
Linux operating systems supported: Yes
Packaging data
Low-profile bracket: Yes
Packaging content
Manual: Yes
Mounting brackets included: Yes
Ports & interfaces
Host interface: PCI Express
Ethernet LAN (RJ-45) ports: 1
Connectivity technology: Wired
Interface: Ethernet
Other features
Quick start guide: Yes
Receive Side Scaling (RSS): Yes
Logistics data
Harmonized System (HS) code: 85176990
