Design
Rack mounting: Yes
Number of fans: 1 fan(s)
Product colour: Black
LED indicators: Yes
Form factor: Desktop
Redundant fans support: Yes
Wall mountable: Yes
Power
Power consumption (max): 40 W
Power source: AC/DC
AC input frequency: 47/63 Hz
AC input voltage: 90 - 264 V
Power cable length: 1.5 m
Power supply included: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Management features
Switch type: Unmanaged
Weight & dimensions
Width: 230 mm
Depth: 330 mm
Weight: 2.54 kg
Height: 44 mm
Network
Networking standards: IEEE 802.3ab, IEEE 802.3u, IEEE 802.3az, IEEE 802.3an, IEEE 802.3ae, IEEE 802.1x, IEEE 802.3bz
Ethernet LAN data rates: 2500
Full duplex: Yes
10G support: Yes
Performance
Noise level: 47 dB
Fanless: No
Mean time between failures (MTBF): 151765 h
Packaging data
AC adapter included: Yes
Packaging content
Quick start guide: Yes
Cables included: Power
Rack mount kit: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), Low Voltage Directive (LVD), ETL, CE, Trade Agreements Act (TAA), National Defense Authorization Act (NDAA)
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
Installed SFP+ modules quantity: 2
Fiber optic connector: SFP+, RJ-45
Power cables quantity: 1
SFP+ module slots quantity: 2
Data transmission
Forwarding rate: 148.8 Mpps
Packet buffer memory: 2 MB
Switching capacity: 200 Gbit/s
MAC address table: 32000 entries
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 12
