Design
Product colour: Black
Reset button: Yes
International Protection (IP) code: IP30
Housing material: Metal
LED indicators: Yes
DIN rail mounting: Yes
Power
Power consumption (max): 253 W
Surge protection: Yes
DC input voltage: 24 - 57 V
Security
DHCP features: DHCP relay, DHCP server
Security algorithms: SSH, SNMP, SNMPv3
Access Control List (ACL): Yes
Loop protection: Yes
BPDU filtering/protection: Yes
IGMP snooping: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -40 - 75 °C
Management features
Web-based management: Yes
System event log: Yes
Switch layer: L2
Quality of Service (QoS) support: Yes
MIB support: MIB II RFC 1213, MIB RFC 1493, RMON (1,2,3,9) RFC 2819 RFC 1757
ARP inspection: Yes
Switch type: Managed
Weight & dimensions
Weight: 930 g
Height: 50 mm
Depth: 120 mm
Width: 160 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Q, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1x, IEEE 802.1AX, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.1w
Full duplex: Yes
VLAN support: Yes
Port mirroring: Yes
Virtual LAN features: MAC address-based VLAN, Tagged VLAN
Broadcast storm control: Yes
Spanning tree protocol: Yes
Number of VLANs: 256
10G support: No
Link aggregation: Yes
MAC address auto-learning supported: Yes
Performance
Firmware upgradeable: Yes
Mean time between failures (MTBF): 562234 h
Packaging data
Terminal block included: Yes
DIN rail included: Yes
Packaging content
Quick start guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 20 Gbit/s
MAC address table: 8000 entries
Packet buffer memory: 128 MB
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 10000
Forwarding rate: 14.88 Mpps
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 8
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Number of multicast groups filtered: 256
