Design
International Protection (IP) code: IP30
Product colour: Black
Rack mounting: No
DIN rail mounting: Yes
LED indicators: Yes
Power
Power consumption (max): 260 W
Output current: 5 A
Output voltage: 48 V
Redundant power supply (RPS) support: Yes
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Security
IGMP snooping: Yes
Authentication: Port-based authentication
DHCP features: DHCP server
Access Control List (ACL): Yes
Security algorithms: HTTPS, 802.1x RADIUS, SNMP
Loop protection: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -40 - 70 °C
Management features
System event log: Yes
Switch layer: L2+
MIB support: RFC 1213, RFC 1493, RFC 1643, RFC 1757
ARP inspection: Yes
Web-based management: Yes
Switch type: Managed
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 920 g
Depth: 132 mm
Width: 170 mm
Height: 50 mm
Network
VLAN support: Yes
Full duplex: Yes
Number of VLANs: 256
10G support: No
Virtual LAN features: Tagged VLAN, Protocol-based VLAN
Spanning tree protocol: Yes
Port mirroring: Yes
Networking standards: IEEE 802.1D, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.3u, IEEE 802.3at
MAC address auto-learning supported: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Performance
Mean time between failures (MTBF): 322805 h
Packaging data
Terminal block included: Yes
Resource CD: Yes
Packaging content
Quick start guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 4
Console port: RJ-45
Basic switching RJ-45 Ethernet ports quantity: 8
Other features
Terminal block port: Yes
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 24 Gbit/s
Jumbo frames support: Yes
Throughput: 17.86 Mpps
Packet buffer memory: 128 MB
Jumbo frames: 10000
MAC address table: 16000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet plus (PoE+) ports quantity: 8
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 240 W
Multicast features
Multicast support: Yes
Multicast MAC address table: 256 entries
