Design
Form factor: 1U
Number of fans: 2 fan(s)
Product colour: Black
Housing material: Linear low-density polyethylene (LLDPE)
Rack mounting: Yes
LED indicators: Yes
Power
Power consumption (max): 446 W
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 30 W
Security
Security algorithms: SSL/TLS, HTTPS, SNMP
MAC address filtering: Yes
IGMP snooping: Yes
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -5 - 50 °C
Management features
Quality of Service (QoS) support: Yes
Web-based management: Yes
Switch type: Managed
Weight & dimensions
Weight: 3.92 kg
Height: 44 mm
Depth: 250 mm
Width: 440 mm
Network
Networking standards: IEEE 802.1ab, IEEE 802.1D, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3af, IEEE 802.3az, IEEE 802.1w, IEEE 802.1x, IEEE 802.3u
Port mirroring: Yes
Full duplex: Yes
VLAN support: Yes
Virtual LAN features: Tagged VLAN, Voice VLAN, Private VLAN, VLAN Identifier ( VLAN ID)
Link aggregation: Yes
Spanning tree protocol: Yes
Head-of-line (HOL) blocking: Yes
Compatible operating systems: Windows® 10, 8.1, 8, 7, Vista, XP, Windows® 2003/2008 Server
Performance
Noise level: 52 dB
Mean time between failures (MTBF): 277.604 h
Packaging data
Resource CD: Yes
Packaging content
Cables included: AC
Quick start guide: Yes
Rack mount kit: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 4
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 56 Gbit/s
Packet buffer memory: 4.1 MB
Jumbo frames support: Yes
MAC address table: 8000 entries
Jumbo frames: 10000
Forwarding rate: 41.7 Mpps
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 24
Multicast features
Multicast support: Yes
Multicast MAC address table: 256 entries
