Design
Product colour: Black
Wall mountable: Yes
LED indicators: PoE, Link, Power, Activity
Housing material: Metal
Power
AC input frequency: 50 - 60 Hz
Power consumption (max): 36 W
DC input voltage: 54 V
AC input voltage: 100 - 240 V
Power source: AC/DC
Input current: 1.2 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Management features
Switch type: Unmanaged
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 75 mm
Height: 26 mm
Weight: 246 g
Width: 121 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3af, IEEE 802.3p
Half duplex: Yes
Full duplex: Yes
VLAN support: Yes
10G support: No
Performance
MTBF (PoE): 3516000 h
Fanless: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports quantity: 5
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 2000 entries
Packet buffer memory: 0.128 MB
Switching capacity: 10 Gbit/s
Jumbo frames: 9000
Jumbo frames support: Yes
Forwarding rate: 7.44 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet plus (PoE+) ports quantity: 4
Total Power over Ethernet (PoE) budget: 32 W
Power over Ethernet (PoE): Yes
Optical fiber
Switching optical modules type: Gigabit Ethernet
