Design
Product colour: Black
LED indicators: Yes
Wall mountable: Yes
Rack mounting: No
Housing material: Metal
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power consumption (max): 71.5 W
Power supply included: Yes
DC input voltage: 55 V
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Management features
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 356 g
Depth: 84 mm
Width: 193 mm
Height: 26 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3u, IEEE 802.3af, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3at
10G support: No
Full duplex: Yes
Performance
Mean time between failures (MTBF): 1401356 h
Packaging content
Cables included: AC
User guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 5
Fiber ports quantity: 1
Fiber optic connector: SFP
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 12 Gbit/s
Forwarding rate: 8298 Mpps
Jumbo frames support: Yes
MAC address table: 2000 entries
Jumbo frames: 9000
Power over Ethernet (PoE)
Power over Ethernet (PoE) type supported: PoE+
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet plus (PoE+) ports quantity: 4
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 65 W
Optical fiber
Fiber ethernet cabling technology: 1000BASE-FX, 100BASE-FX
