Design
IK code: IK04
International Protection (IP) code: IP65
Housing material: Polycarbonate (PC), Aluminium
Product colour: Black
Weatherproof: Yes
Mounting type: Ceiling/Wall/Pole
Form factor: Bullet
Power
DC output voltage: 48, 54, 57
Power source type: PoE
Power consumption (max): 11 W
Operational conditions
Operating temperature (T-T): -20 - 50 °C
Operating relative humidity (H-H): 0 - 90%
Management features
Reset button: Yes
Weight & dimensions
Diameter: 8.6 cm
Length: 175.3 mm
Weight: 820 g
Network
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
Bluetooth: No
Wi-Fi: No
Certification: FCC, IC, CE
Performance
Connectivity technology: Wired
Built-in processor: Yes
Type: IP security camera
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor & outdoor
Packaging content
Mounting kit: Yes
Number of cameras: 1
Audio
Built-in microphone: Yes
Audio system: 2-way
Built-in speaker(s): Yes
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, vertical: 19.7, 59.9°
Lens viewing angle, horizontal: 34.9, 109.9°
Lens viewing angle, diagonal: 40, 127.7°
Image sensor
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Video
Total megapixels: 8 MP
Frame rate: 30 fps
Noise reduction: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Image quality adjustment: Sharpness, Brightness, Contrast
Maximum resolution: 3840 x 2160 pixels
Video compression formats: H.264
Night vision
Night vision distance: 25 m
Night vision: Yes
LED type: IR
Lens system
Optical zoom: 3x
Maximum aperture number: 3.3
Zoom capability: Yes
Focal length range: 4.1 - 12.3 mm
Minimum aperture number: 1.53
