Design
Product colour: White
Mounting type: Ceiling/wall
Power
DC output voltage: 37, 48, 54, 57
Power consumption (max): 12.5 W
Power source type: PoE
Operational conditions
Operating temperature (T-T): -20 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Reset button: Yes
Weight & dimensions
Weight: 58 g
Height: 58.9 mm
Diameter: 3.66 cm
Cable length: 1 m
Network
Ethernet interface type: Gigabit Ethernet
Bluetooth: No
Ethernet LAN: Yes
Wi-Fi: No
Certification: FCC, IC, CE
Performance
Connectivity technology: Wired
Type: IP security camera
Processor model: ARM Cortex-A53
Built-in processor: Yes
Placement supported: Indoor
Packaging content: AI Theta Hub
Packaging content
Number of cameras: 1
Mounting kit: Yes
Manual: Yes
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, diagonal: 180°
Lens viewing angle, vertical: 180°
Lens viewing angle, horizontal: 180°
Image sensor
Sensor type: CMOS
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Video
Frame rate: 24 fps
Noise reduction: Yes
Image quality adjustment: Contrast, Sharpness, Brightness
Maximum resolution: 2160 x 2160 pixels
Video compression formats: H.264
Total megapixels: 4 MP
Noise reduction technology: 2D noise reduction, 3D noise reduction
Night vision
Night vision: No
Lens system
Number of lenses: 1
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
