Features
Processor frequency: 1500 MHz
Processor cores: 4
Bluetooth: Yes
Internal memory: 3000 MB
Number of simultaneously connected devices (max): 300
Processor architecture: ARM Cortex-A53
Built-in processor: Yes
Design
Product colour: White
LED indicators: Status
Built-in display: Yes
Product type: Tabletop router
Display type: LCM
Housing material: Polycarbonate (PC)
Power
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (typical): 26 W
Power source type: AC, PoE
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) voltage: 57 V
Power supply: 50 W
Security
Security algorithms: WPA, WPA2, PPSK, WPA-Enterprise, WPA-PSK, WPA3
Filtering: Yes
MAC address table: 2000 entries
Firewall: Yes
Operational conditions
Operating temperature (T-T): -10 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Management features
Reset button: Yes
MIMO: Yes
Quality of Service (QoS) support: Yes
Web-based management: Yes
MU-MIMO technology: Yes
Weight & dimensions
Weight: 1.1 kg
Width: 110 mm
Height: 184.1 mm
Depth: 110 mm
Network
Networking standards: IEEE 802.1Q
Maximum Tx power (2.4 GHz): 23 dBmW
Maximum Tx power (5 GHz): 26 dBmW
Ethernet LAN data rates: 2500 Mbit/s
Multicast support: Yes
Ethernet LAN: Yes
Load balancing system: Yes
Policy-based routing: Yes
VPN server: Identity Endpoint One-Click VPN, Teleport Zero-Configuration VPN, WireGuard, OpenVPN, L2TP
Maximum coverage: 160 m²
Ethernet LAN interface type: 2.5 Gigabit Ethernet
Packaging data
Number of products included: 1 pc(s)
Packaging content
Cables included: AC
Manual: Yes
Wireless LAN features
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), 802.11b
WLAN data transfer rate (max): 5700 Mbit/s
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz)
WLAN data transfer rate (second band): 4300 Mbit/s
WLAN data transfer rate (third band): 5700 Mbit/s
WLAN data transfer rate (first band): 688 Mbit/s
Certificates
Compliance certificates: CE, Industry Canada (IC), Federal Communications Commission (FCC)
Protocols
Routing protocols: OSPF
DHCP server: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 4
Fiber optic connector: SFP+
Compatible memory cards: MicroSD (TransFlash)
Memory card slot(s): Yes
USB port: No
Antenna
Antenna gain level (max): 7 dBi
Antenna design: Internal
WAN connection
Ethernet WAN: Yes
3G/4G USB modem compatibility: No
DSL WAN: No
SIM card slot: No
