Design
Mounting type: Wall/Pole
Housing material: Polycarbonate (PC), Aluminium
IK code: IK04
International Protection (IP) code: IPX4
Product colour: White, Black
Form factor: Bullet
Power
DC output voltage: 57
Power source type: PoE
Power consumption (max): 4 W
Operational conditions
Operating temperature (T-T): -20 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Management features
Management software: UniFi Protect
Reset button: Yes
Weight & dimensions
Diameter: 7.55 cm
Length: 74.4 mm
Weight: 225 g
Network
Ethernet interface type: 10 Gigabit Ethernet, 100 Gigabit Ethernet
Bluetooth: No
Ethernet LAN: Yes
Wi-Fi: No
Performance
Placement supported: Indoor & outdoor
Infrared (IR) cut-off filter: Yes
Built-in processor: Yes
Processor model: ARM Cortex-A7
Connectivity technology: Wired
Packaging content
Number of cameras: 3
Audio
Built-in microphone: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, vertical: 45.4°
Lens viewing angle, diagonal: 99.8°
Lens viewing angle, horizontal: 84.4°
Image sensor
Sensor type: CMOS
Video
Text caption overlay: Yes
Frame rate: 30 fps
Noise reduction technology: 2D noise reduction, 3D noise reduction
Image quality adjustment: Contrast, Sharpness, Brightness
Supported video modes: 1512p
Video compression formats: H.264, M-JPEG
Privacy masking: Yes
Total megapixels: 5 MP
Noise reduction: Yes
Maximum resolution: 2688 x 1512 pixels
Supported graphics resolutions: 2688 x 1512
Night vision
Night vision: Yes
LED type: IR
Lens system
Number of lenses: 1
Sustainability
Sustainability compliance: Yes
Compliance certificates: CE, Federal Communications Commission (FCC)
