Technical details
Sustainability certificates: CE, Federal Communications Commission (FCC)
Sustainability compliance: Yes
Design
Housing material: Aluminium, Polycarbonate (PC)
Product colour: Black, White
Form factor: Bullet
IK code: IK04
International Protection (IP) code: IPX4
Mounting type: Wall/Pole
Power
Power consumption (max): 4 W
DC output voltage: 57
Power source type: PoE
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -20 - 40 °C
Management features
Reset button: Yes
Management software: UniFi Protect
Weight & dimensions
Weight: 225 g
Diameter: 7.55 cm
Length: 74.4 mm
Network
Wi-Fi: No
Ethernet interface type: 100 Gigabit Ethernet, 10 Gigabit Ethernet
Ethernet LAN: Yes
Bluetooth: No
Performance
Processor model: ARM Cortex-A7
Built-in processor: Yes
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, diagonal: 99.8°
Lens viewing angle, horizontal: 84.4°
Lens viewing angle, vertical: 45.4°
Image sensor
Sensor type: CMOS
Video
Supported graphics resolutions: 2688 x 1512
Frame rate: 30 fps
Maximum resolution: 2688 x 1512 pixels
Video compression formats: M-JPEG, H.264
Noise reduction: Yes
Supported video modes: 1512p
Total megapixels: 5 MP
Image quality adjustment: Contrast, Sharpness, Brightness
Noise reduction technology: 2D noise reduction, 3D noise reduction
Privacy masking: Yes
Text caption overlay: Yes
Night vision
LED type: IR
Night vision: Yes
Lens system
Number of lenses: 1
