Design
Product colour: Black
Housing material: Polycarbonate (PC), Aluminium, Stainless steel
Mounting type: Ceiling/wall
IK code: IK06
Protection features: Vandal proof
Form factor: Dome
Power
AC input voltage: 37 - 57 V
Power source type: PoE
Power consumption (typical): 4.2 W
Operational conditions
Operating temperature (T-T): -20 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Reset button: Yes
Weight & dimensions
Weight: 175 g
Diameter: 6.36 cm
Height: 68.2 mm
Network
Bluetooth: No
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Fast Ethernet
Performance
Connectivity technology: Wired
Type: IP security camera
Placement supported: Indoor & outdoor
Processor model: ARM Cortex-A7
Day/night mode: Yes
Infrared (IR) cut-off filter: Yes
Built-in processor: Yes
Packaging content
Number of cameras: 1
Screws included: Yes
Cables included: LAN (RJ-45)
Mounting kit: Yes
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, vertical: 54.9°
Lens viewing angle, diagonal: 120.6°
Lens viewing angle, horizontal: 102.4°
Image sensor
Number of sensors: 1
Sensor type: CMOS
Optical sensor size: 25.4 / 2.4 mm (1 / 2.4")
Video
Maximum resolution: 2688 x 1512 pixels
Video formats supported: H.264
Frame rate: 30 fps
Noise reduction technology: 2D noise reduction, 3D noise reduction
Text caption overlay: Yes
Privacy masking: Yes
Total megapixels: 4 MP
Noise reduction: Yes
Night vision
LED type: IR
Night vision: Yes
Night vision distance: 20 m
Lens system
Number of lenses: 1
Sustainability
Compliance certificates: Federal Communications Commission (FCC), Industry Canada (IC), CE
