Technical details
Sustainability compliance: Yes
Compliance certificates: Federal Communications Commission (FCC), CE
Design
Housing material: Aluminium, Polycarbonate (PC)
International Protection (IP) code: IP66
Product colour: White
Protection features: UV resistant, Tamper resistant
Form factor: Turret
IK code: IK04
Mounting type: Ceiling/wall
Weatherproof: Yes
Power
AC input voltage: 37 - 57 V
Power source type: PoE
Power consumption (typical): 4 W
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -30 - 50 °C
Management features
Reset button: Yes
Weight & dimensions
Height: 71.2 mm
Cable length: 0.3 m
Weight: 330 g
Diameter: 9 cm
Network
Ethernet LAN: Yes
Bluetooth: No
Ethernet interface type: Fast Ethernet
Wi-Fi: No
Performance
Processor model: ARM Cortex-A7
Type: IP security camera
Connectivity technology: Wired
Day/night mode: Yes
Built-in processor: Yes
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor & outdoor
Packaging content
Number of cameras: 1
Cables included: LAN (RJ-45)
Mounting kit: Yes
Screws included: Yes
Audio
Built-in microphone: Yes
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, diagonal: 120.6°
Lens viewing angle, horizontal: 102.4°
Lens viewing angle, vertical: 54.9°
Image sensor
Optical sensor size: 25.4 / 2.4 mm (1 / 2.4")
Sensor type: CMOS
Number of sensors: 1
Video
Maximum resolution: 2688 x 1512 pixels
Image quality adjustment: Contrast, Sharpness, Brightness, DNR, Colour depth
Privacy masking: Yes
Frame rate: 30 fps
Noise reduction: Yes
Text caption overlay: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Video formats supported: H.264
Total megapixels: 4 MP
Night vision
LED type: IR
Night vision distance: 30 m
Night vision: Yes
Lens system
Number of lenses: 1
