Technical details
Night mode: Yes
Design
IK code: IK10
Weatherproof: Yes
Housing material: Aluminium, Polycarbonate (PC)
Form factor: Dome
Protection features: Vandal proof, Weatherproof
International Protection (IP) code: IP66
Mounting type: Ceiling/wall
Product colour: White
Power
DC output voltage: 37, 42.5, 48, 54, 57
Power source type: PoE+
Power consumption (max): 7.14 W
Security
Intelligent Video Surveillance (IVS) system features: Human detection, Vehicle detection, Pet detection
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -30 - 50 °C
Management features
Reset button: Yes
Weight & dimensions
Height: 65.5 mm
Diameter: 14.7 cm
Weight: 610 g
Network
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Wi-Fi: No
Bluetooth: No
Performance
Infrared (IR) cut-off filter: Yes
Day/night mode: Yes
Placement supported: Indoor & outdoor
Built-in processor: Yes
Connectivity technology: Wired
Type: IP security camera
Processor model: ARM Cortex-A53
Packaging content
Number of cameras: 1
Screws included: Yes
Mounting kit: Yes
Manual: Yes
Audio
Built-in speaker(s): Yes
Number of microphones: 2
Built-in microphone: Yes
Audio system: 2-way
Storage
Built-in HDD: No
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Camera pan control: Yes
Lens viewing angle, vertical: 180°
Camera tilt control: Yes
Lens viewing angle, horizontal: 180°
Lens viewing angle, diagonal: 180°
Image sensor
Optical sensor size: 25.4 / 1.6 mm (1 / 1.6")
Video
Frame rate: 24 fps
Text caption overlay: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Noise reduction: Yes
Image quality adjustment: Colour depth, Sharpness, HDR, Brightness, Contrast
Total megapixels: 12 MP
Maximum resolution: 3504 x 3504 pixels
Privacy masking: Yes
Night vision
Night vision distance: 15 m
Night vision: Yes
LED type: IR
Lens system
Zoom capability: Yes
Number of lenses: 1
Sustainability
Compliance certificates: Industry Canada (IC), National Defense Authorization Act (NDAA), CE, Federal Communications Commission (FCC)
