Technical details
Night mode: Yes
Features
License plate recognition: Yes
Design
Housing material: Polycarbonate (PC), Aluminium
IK code: IK04
International Protection (IP) code: IP66
Weatherproof: Yes
Form factor: Bullet
Mounting type: Ceiling/Wall/Pole
Product colour: White
Power
Power consumption (max): 15 W
Power source type: PoE
DC output voltage: 37, 42.5, 48, 54, 57
Security
Light sensor: Yes
Human and vehicle targets classification: Yes
Operational conditions
Operating temperature (T-T): -20 - 50 °C
Operating relative humidity (H-H): 0 - 90%
Management features
Reset button: Yes
Weight & dimensions
Weight: 755 g
Diameter: 8.58 cm
Length: 210 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Bluetooth: No
Performance
Processor model: ARM Cortex-A53
Type: IP security camera
Placement supported: Indoor & outdoor
Infrared (IR) cut-off filter: Yes
Connectivity technology: Wired
Built-in processor: Yes
Day/night mode: Yes
Packaging content
Mounting kit: Yes
Number of cameras: 1
Screws included: Yes
Manual: Yes
Audio
Built-in speaker(s): Yes
Audio system: 2-way
Built-in microphone: Yes
Number of microphones: 2
Storage
Built-in HDD: No
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, vertical: 25.8 , 61.9°
Lens viewing angle, horizontal: 45.5, 113.8°
Lens viewing angle, diagonal: 52, 134°
Image sensor
Sensor type: CMOS
Optical sensor size: 25.4 / 1.2 mm (1 / 1.2")
Video
Total megapixels: 8 MP
Image quality adjustment: Sharpness, Contrast, HDR, Brightness, Colour depth
Maximum resolution: 3840 x 2160 pixels
Noise reduction: Yes
Frame rate: 30 fps
Text caption overlay: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Privacy masking: Yes
Night vision
Night vision distance: 40 m
LED type: IR
Night vision: Yes
Lens system
Focal length range: 5.9 - 13.8 mm
Maximum aperture number: 2.9
Minimum aperture number: 1.5
Zoom capability: Yes
Optical zoom: 2.36x
Sustainability
Compliance certificates: National Defense Authorization Act (NDAA), CE, Federal Communications Commission (FCC), Industry Canada (IC)
