Design
Weatherproof: Yes
Mounting type: Ceiling/wall
Housing material: Aluminium, Polycarbonate (PC)
International Protection (IP) code: IP66
IK code: IK04
Product colour: White
Form factor: Turret
Power
DC output voltage: 42.5, 48, 54, 57
Power consumption (max): 15 W
Power source type: PoE+
Security
Human and vehicle targets classification: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -30 - 50 °C
Management features
Reset button: Yes
Weight & dimensions
Height: 116.5 mm
Diameter: 11.7 cm
Weight: 1.2 kg
Network
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: No
Bluetooth: No
Performance
Placement supported: Indoor & outdoor
Infrared (IR) cut-off filter: Yes
Built-in processor: Yes
Type: IP security camera
Processor model: ARM Cortex-A53
Connectivity technology: Wired
Packaging content
Mounting kit: Yes
Number of cameras: 1
Manual: Yes
Audio
Built-in speaker(s): Yes
Built-in microphone: Yes
Audio system: 2-way
Storage
Built-in HDD: No
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Camera tilt control: Yes
Camera pan control: Yes
Lens viewing angle, vertical: 61.9 - 25.8°
Lens viewing angle, diagonal: 134 - 52°
Lens viewing angle, horizontal: 113.8 - 45.5°
Angle of rotation: 360°
Image sensor
Sensor type: CMOS
Optical sensor size: 25.4 / 1.2 mm (1 / 1.2")
Number of sensors: 1
Video
Noise reduction technology: 2D noise reduction, 3D noise reduction
Video recording: Yes
Frame rate: 30 fps
Image quality adjustment: Sharpness, Contrast, White balance, Brightness
Total megapixels: 8 MP
Noise reduction: Yes
Maximum resolution: 3840 x 2160 pixels
Night vision
Night vision: Yes
Night vision distance: 40 m
LED type: IR
Lens system
Maximum aperture number: 2.9
Minimum aperture number: 1.5
Focal length range: 5.85 - 13.8 mm
Zoom capability: Yes
Optical zoom: 2.36x
Sustainability
Compliance certificates: Industry Canada (IC), National Defense Authorization Act (NDAA), CE, Federal Communications Commission (FCC)
