Design
Mounting type: Ceiling/wall
IK code: IK04
Product colour: Black
LED indicators: Yes
International Protection (IP) code: IP66
Housing material: Aluminium, Polycarbonate (PC)
Weatherproof: Yes
Form factor: Turret
Power
Power source type: PoE
Power consumption (max): 12.5 W
DC output voltage: 37, 42.5, 48, 54, 57
Security
Human and vehicle targets classification: Yes
Light sensor: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -30 - 50 °C
Management features
Reset button: Yes
Weight & dimensions
Height: 95 mm
Weight: 550 g
Diameter: 10 cm
Network
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Wi-Fi: No
Bluetooth: No
Performance
Type: IP security camera
Processor model: ARM Cortex-A53
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor & outdoor
Built-in processor: Yes
Connectivity technology: Wired
Packaging content
Mounting kit: Yes
Number of cameras: 1
Manual: Yes
Screws included: Yes
Audio
Built-in microphone: Yes
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, vertical: 56.7°
Lens viewing angle, horizontal: 109.9°
Lens viewing angle, diagonal: 134.1°
Angle of rotation: 360°
Camera pan control: Yes
Camera tilt control: Yes
Image sensor
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Video
Privacy masking: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Image quality adjustment: Sharpness, Contrast, HDR, Brightness
Total megapixels: 8 MP
Maximum resolution: 3864 x 2160 pixels
Frame rate: 30 fps
Noise reduction: Yes
Text caption overlay: Yes
Night vision
LED type: IR
Night vision: Yes
Night vision distance: 30 m
Sustainability
Compliance certificates: CE, National Defense Authorization Act (NDAA), Federal Communications Commission (FCC), Industry Canada (IC)
