Ubiquiti PoE adapters offer various features to protect your PoE devices:
- Surge protection
- Clamping protection
- Maximum surge discharge
- Maximum impulse current
- Grounded AC cable
Electrostatic discharge (ESD) is the main cause of damage to external devices.
With the grounded Ubiquiti PoE adapter, TOUGHCableTM, and TOUGHCable connectors, you can effectively protect yourself from ESD damage.
Specifications:
POE-24-24W-G
Dimensions
96 x 62 x 35 mm (3.78 x 2.44 x 1.38")
Weight
166 g
Output Voltage
24VDC @ 1.0A
LAN Activity Indicator
No
Gigabit LAN Port
Yes
Remote Reset Capability
Yes
Reset Button
Yes
Rated Voltage
100-240VAC @ 50/60Hz
Input Current
750mA @ 90VAC
Inrush Current
<100A Peak @ 25°C
Efficiency
86.2+%
Output Ripple
200mV p-p
Switching Frequency
65 kHz
Line Regulation
≤ 3
Load Regulation
≤ 5
2-Pair Powering
Pins 4, 5 (+) and Pins 7, 8 (-)
4-Pair Powering
-
Operating Temperature
0 to 40° C
(32 to 104° F)
Storage Temperature
-30 to 70°C
(-22 to 158° F)
Operating Humidity
5 to 95% Noncondensing
AC Connector
IEC-320 C6
Data IN / POE
RJ45 Shielded Socket
Surge Protection
Difference and Common Mode
Clamping Protection
11V Data, 60V Power
Max. Surge Discharge
1500A (8/20 μs) Power
Peak Pulse Current
36A (10/1000 μs) Data
Shunt Capacitance
<5 pF data
Response Time
<1 ns
Certifications
CE, FCC, IC, UL
Official manufacturer website: https://store.ui.com/collections/operator-accessories/products/poe-injector-24vdc-24w-gbit-white
