Features
Antenna type: Internal
Antenna connector type: RP-SMA
Antennas quantity: 2
Antenna gain level (max): 5 dBi
Design
Mounting type: Rack/Desktop/Wall
LED indicators: Status
Product colour: Black
Power
Electrostatic Discharge (ESD) protection (air): 8 kV
Electrostatic Discharge (ESD) protection (contact): 4 kV
DC input voltage: 50 - 57 V
Electrostatic Discharge (ESD) protection: Yes
Electromagnetic (EMP) protection (contact): 4 kV
Power supply: 350 W
Electromagnetic (EMP) protection (air): 8 kV
Power consumption (max): 28 W
Input voltage: 100 - 240 V
Electromagnetic (EMP) protection: Yes
Heat dissipation: 85 BTU/h
Power over Ethernet (PoE): Yes
Security
Network address translation (NAT): Yes
VLAN support: Yes
Firewall security: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -30 - 50 °C
Management features
Reset button: Yes
Multicast support: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 203.5 mm
Height: 43.7 mm
Width: 307.9 mm
Weight: 2.4 kg
Network
Ethernet LAN data rates: 10000 Mbit/s, 1000 Mbit/s, 2500
Networking standards: IEEE 802.11ax, IEEE 802.11g, IEEE 802.11n, IEEE 802.11a, IEEE 802.11be, IEEE 802.11b, IEEE 802.11ac
Load balancing: Yes
Data transfer rate: 4.3 Gbit/s
WLAN data transfer rates supported: 12, 24, 54, 2, 48, 18, 9, 11, 6, 36, 1732 Mbit/s, 2402, 6.5, 5.5, 1
Wi-Fi: Yes
Performance
Internal memory type: DDR4
Built-in processor: Yes
Processor family: ARM Cortex
Control display unit: No
Number of processors installed: 1
Processor frequency: 2200 MHz
Processor manufacturer: ARM
Internal memory: 3000 MB
Packaging content
AC adapter included: Yes
Manual: Yes
Certificates
Compliance certificates: CE, National Defense Authorization Act (NDAA), Industry Canada (IC), Federal Communications Commission (FCC)
Ports & interfaces
SFP+ ports quantity: 1
Ethernet LAN (RJ-45) ports: 5
WAN connection: Ethernet (RJ-45), SFP+
Number of simultaneous SIM cards: 2
DC-in jack: Yes
SIM card slot: Yes
