Design
Redundant fans support: Yes
Rack mounting: Yes
Number of fans: 4 fan(s)
Display type: LCM
Product colour: Grey
LED indicators: Status, Link, Activity
Housing material: SGCC
Form factor: 1U
Reset button: Yes
Power
Power supply included: Yes
Number of power supply units: 2
AC input frequency: 50/60 Hz
Redundant power supply (RPS) support: Yes
Power source: AC
AC input voltage: 100 - 240 V
Power consumption (max): 2400 W
Security
Loop protection: Yes
IGMP snooping: Yes
DHCP features: DHCP relay, DHCP snooping, DHCP guarding
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -5 - 40 °C
Management features
Switch type: Managed
Switch layer: L2/L3
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 496 mm
Height: 43.7 mm
Width: 442 mm
Weight: 9.46 kg
Network
IPv4 routes: 256000
Virtual LAN features: Voice VLAN
VLAN support: Yes
Port mirroring: Yes
Number of VLANs: 1000
Broadcast storm control: Yes
Link aggregation: Yes
Rate limiting: Yes
10G support: Yes
Flow control support: Yes
Networking standards: IEEE 802.1x, IEEE 802.3bt
Ethernet LAN data rates: 10,100,1000,2500,5000,10000 Mbit/s
Packaging data
Mounting brackets included: Yes
Rack rails: Yes
Packaging content
Rack mount kit: Yes
Cables included: Power
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC), Industry Canada (IC)
Ports & interfaces
SFP28 ports quantity: 4
10G Ethernet (copper) ports quantity: 32
2.5G Ethernet (copper) ports quantity: 16
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports quantity: 48
SFP module slots quantity: 4
Data transmission
Switching capacity: 920 Gbit/s
MAC address table: 128000 entries
Jumbo frames support: Yes
Packet buffer memory: 8 MB
Static route: Yes
Forwarding rate: 684 Mpps
Throughput: 460 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 90 W
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 2150 W
Power over Ethernet (PoE) type supported: PoE+, PoE++ (4PPoE)
Multicast features
Multicast support: Yes
