Features
Antenna type: Internal
Antennas quantity: 4
Antenna gain level (max): 6 dBi
Design
Product colour: White
LED indicators: Status
Enclosure material: Polycarbonate (PC)
Power
Input voltage: 100 - 240 V
Input current: 5 A
Electromagnetic (EMP) protection (contact): 4 kV
Power consumption (max): 22 W
Electromagnetic (EMP) protection (air): 8 kV
Electromagnetic (EMP) protection: Yes
Security
Security algorithms: WPA-Enterprise, 802.1x RADIUS, IPSec, WPA, WPA-PSK, WPA3, WPA2, PPSK, TLS
VLAN support: Yes
Firewall security: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -10 - 40 °C
Management features
Reset button: Yes
Multicast support: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 117 mm
Height: 42.5 mm
Weight: 422 g
Depth: 117 mm
Network
Ethernet LAN data rates: 2500 Mbit/s, 10, 10000 Mbit/s, 1000 Mbit/s, 100
Bluetooth: Yes
WLAN data transfer rates supported: 6, 1, 36, 300 Mbit/s, 12, 24, 54, 9, 11, 6.5, 18, 2, 48, 5.5
Frequency band: 2.4, 5, 6 GHz
Networking standards: IEEE 802.1Q
Data transfer rate: 5.7 Gbit/s
Wireless connection: Yes
Wi-Fi: Yes
Load balancing: Yes
Performance
Processor frequency: 1500 MHz
Processor model: Cortex-A53
Control display unit: Yes
Processor family: ARM Cortex
Processor manufacturer: ARM
Number of processors installed: 1
Built-in processor: Yes
Internal memory: 3000 MB
Display type: LCM
Packaging content
Cables included: Power, LAN (RJ-45)
AC adapter included: Yes
Display
Display diagonal: 2.44 cm (0.96")
Certificates
Compliance certificates: Federal Communications Commission (FCC), Industry Canada (IC), CE
Protocols
DHCP server: Yes
Routing protocols: OSPF
Ports & interfaces
WAN connection: Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports: 2
