Technical details
Product colour: White
Reset button: Yes
Compliance certificates: RCM, BSMI, KC, National Defense Authorization Act (NDAA), Federal Communications Commission (FCC), CE, TÜV mark, Industry Canada (IC), UL
Power
AC input voltage: 100 - 240 V
Power over Ethernet (PoE): Yes
Power consumption (max): 9 W
AC input frequency: 50/60 Hz
Power source type: AC
Operational conditions
Camera operating temperature (T-T): -30 - 50 °C
Camera operating relative humidity (H-H): 0 - 90%
Recorder operating temperature (T-T): 0 - 40 °C
Recorder operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Height: 47 mm
Width: 220 mm
Depth: 220 mm
Network
Ethernet LAN: Yes
Packaging content
Cables included: Power
Display
Display diagonal: 2.9 cm (1.14")
Placement: Wall, Desk
Display type: LCM
Audio
Built-in microphone: Yes
Camera
Megapixel (approx.): 4 MP
Camera interface: RJ-45
Viewing angle, horizontal: 102.4°
Optical sensor size: 25.4 / 2.4 mm (1 / 2.4")
Night mode: Yes
Viewing angle, diagonal: 120.6°
Surveillance camera form factor: Turret
Camera included: Yes
Sensor type: CMOS
Day/night mode: Yes
Weatherproof: Yes
Colour: Yes
Housing material: Polycarbonate (PC)
Camera resolution: 2688 x 1512 pixels
Connectivity technology: Wired
Infrared (IR) cut-off filter: Yes
Viewing angle, vertical: 54.9°
International Protection (IP) code: IP66
Number of cameras: 4
LED type: IR
Night vision distance: 30 m
Placement supported: Indoor/outdoor
Logistics data
Harmonized System (HS) code: 85219000
Recorder
Ethernet LAN (RJ-45) ports: 7
Total Power over Ethernet (PoE) budget: 40 W
LED indicators: PoE, LAN
Storage media type: HDD
Power over Ethernet (PoE) power per port: 15.4 W
Power over Ethernet (PoE) ports quantity: 6
Number of HDDs installed: 1
HDD size: 3.5"
HDMI ports quantity: 1
Recorder included: Yes
HDD interface: SATA
Total storage capacity: 1 TB
Card reader integrated: No
HDD capacity: 1 TB
