Design
Product colour: White
Form factor: Dome
Housing material: Stainless steel, Polycarbonate (PC), Aluminium
International Protection (IP) code: IPX4
Mounting type: Ceiling/wall
IK code: IK08
Power
AC input voltage: 37 - 57 V
Power source type: PoE
Power consumption (typical): 5 W
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -20 - 40 °C
Management features
Reset button: Yes
Weight & dimensions
Depth: 64.2 mm
Diameter: 10.9 cm
Weight: 390 g
Network
Bluetooth: No
Ethernet interface type: Fast Ethernet
Wi-Fi: No
Ethernet LAN: Yes
Certification: FCC, IC, CE
Performance
Connectivity technology: Wired
Built-in processor: Yes
Type: IP security camera
Placement supported: Indoor & outdoor
Processor model: ARM Cortex-A7
Packaging content
Cables included: LAN (RJ-45)
Mounting kit: Yes
Number of cameras: 1
Audio
Built-in microphone: Yes
Built-in speaker(s): Yes
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Camera pan control: Yes
Lens viewing angle, diagonal: 134.3°
Lens viewing angle, horizontal: 102.4°
Lens viewing angle, vertical: 71.4°
Image sensor
Sensor type: CMOS
Number of sensors: 1
Video
Maximum resolution: 2688 x 1512 pixels
Frame rate: 30 fps
Image quality adjustment: Colour depth, Brightness, DNR, Contrast
Total megapixels: 5 MP
Noise reduction technology: 3D noise reduction
Video compression formats: H.264, M-JPEG
Noise reduction: Yes
Night vision
Night vision distance: 10 m
LED type: IR
Night vision: Yes
Lens system
Number of lenses: 1
