Design
Handset type: Wired handset
Product type: IP Phone
Product colour: Black
Power
Power over Ethernet (PoE): Yes
Operational conditions
Operating temperature (T-T): 5 - 70 °C
Storage temperature (T-T): -40 - 70 °C
Management features
Volume control: Buttons
Number of programmable keys: 16
Weight & dimensions
Weight: 1.2 kg
Height: 143 mm
Depth: 165 mm
Width: 283 mm
Network
Ethernet LAN interface type: Gigabit Ethernet
Supported network protocols: IP v4/v6 (SIP) IPv4 (HFA), DHCP,
Ethernet LAN: Yes
Security algorithms: HTTPS, 256-bit AES, 128-bit AES
Networking standards: IEEE 802.3az
Bluetooth: No
Ethernet LAN data rates: 10,100,1000 Mbit/s
VoIP protocols: SIP, HFA
Performance
Operating system installed: Linux
Packaging content
Base station: Yes
Display
Backlight display: Yes
Display diagonal: 9.4 cm (3.7")
Display resolution: 240 x 120 pixels
Touchscreen: No
Audio
Echo cancellation: Yes
Ringer type: MP3
Voice codecs: G.729, G.729A, G.711, G.729B, G.722
Speakerphone: Yes
Certification: CE
NRTL
FCC Part 68 (CFR 47) / CS-03 Part V
Certificates
Safety: CISPR22 Class B, CISPR 24 EN55032 Class B, EN55024 FCC Part 15 (CFR 47) Class B
Ports & interfaces
Headset connectivity: DHSG/EHS
Camera
Front camera: No
Logistics data
Harmonized System (HS) code: 85171800
Phone features
Phonebook capacity: 1000 entries
Full duplex: Yes
