Design
IK code: IK10
International Protection (IP) code: IP67
Form factor: Bullet
Housing material: Metal
Product colour: White
Mounting type: Ceiling/wall
Power
Power consumption (max): 8 W
Power source type: DC, PoE
DC output voltage: 12
Security
Alarm output channels: 1
Alarm input channels: 1
Video motion detection: Yes
Privacy protection: Yes
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -30 - 60 °C
Management features
Web-based management: Yes
Web browser: Yes
Weight & dimensions
Weight: 920 g
Length: 245 mm
Height: 72 mm
Width: 86 mm
Network
Ethernet interface type: Fast Ethernet
Wi-Fi: No
Networking standards: IEEE 802.3af
Supported network protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
Bluetooth: No
Ethernet LAN: Yes
Quality of Service (QoS) support: Yes
Performance
Placement supported: Outdoor
Connectivity technology: Wired
Type: IP security camera
Dynamic range: 120 dB
Wide Dynamic Range (WDR): Yes
Packaging content
Number of cameras: 1
Audio
Sample rate: 8 kHz
Audio formats supported: G.711
Signal-to-Noise Ratio (SNR): 56 dB
Audio system: 2-way
Bit rate range: 128 - 16000 Kbit/s
Storage
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Built-in HDD: No
Maximum memory card size: 256 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Camera
White balance: Sodium lamp, Auto, Outdoor, Fine
Pan range: 0 - 360°
Adjustment shutter speed: Auto/Manual
Camera pan control: Yes
Camera tilt control: Yes
Angle of rotation: 360°
Camera shutter speed: 1 - 1/100000 s
Camera shutter type: Electronic
Minimum illumination: 0.002 lx
Tilt angle range: 0 - 90°
Lens viewing angle, vertical: 56.36°
Lens viewing angle, horizontal: 106.25°
Lens viewing angle, diagonal: 110.34°
Logistics data
Harmonized System (HS) code: 85258900
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Back Light Compensation (BLC): Yes
Supported graphics resolutions: 2560 x 1440, 2880 x 1620, 640 x 360, 1920 x 1080 (HD 1080), 2304 x 1296, 352 x 288, 720 x 576, 704 x 288, 1280 x 720 (HD 720)
Total megapixels: 5 MP
Region of Interest (ROI) encoding: Yes
Video compression formats: M-JPEG, H.264, H.265
Noise reduction: Yes
Maximum resolution: 2880 x 1620 pixels
Noise reduction technology: 2D noise reduction, 3D noise reduction
Smart IR: Yes
Privacy masking: Yes
Highlight Compensation (HLC): Yes
Night vision
Night vision distance: 50 m
LED type: IR
Infra-red wavelength: 850 nm
Night vision: Yes
Lens system
Zoom capability: Yes
Auto focus: Yes
Focal length range: 2.7 - 13.5 mm
Focus: Motorized
