Design
Product colour: White
Form factor: Turret
International Protection (IP) code: IP67
Mounting type: Ceiling/wall
IK code: IK10
Housing material: Metal
Power
Power source type: DC, PoE
Power consumption (max): 9 W
DC output voltage: 12
Security
Video motion detection: Yes
Privacy protection: Yes
Operational conditions
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -30 - 60 °C
Operating temperature (T-T): -30 - 60 °C
Management features
Web-based management: Yes
Web browser: Yes
Weight & dimensions
Weight: 690 g
Diameter: 12.9 cm
Height: 110 mm
Network
Bluetooth: No
Networking standards: IEEE 802.3af
Supported network protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Fast Ethernet
Quality of Service (QoS) support: Yes
Performance
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Placement supported: Outdoor
Dynamic range: 120 dB
Infrared (IR) cut-off filter: Yes
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Signal-to-Noise Ratio (SNR): 56 dB
Sample rate: 8 kHz
Audio formats supported: G.711
Storage
Maximum memory card size: 256 GB
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
Built-in HDD: No
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Tilt angle range: 0 - 75°
Adjustment shutter speed: Auto/Manual
Angle of rotation: 360°
Camera shutter speed: 1 - 1/100000 s
White balance: Sodium lamp, Outdoor, Auto, Fine
Camera shutter type: Electronic
Pan range: 0 - 360°
Minimum illumination: 0.003 lx
Logistics data
Harmonized System (HS) code: 85258900
Image sensor
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Progressive scan: Yes
Video
Supported graphics resolutions: 704 x 288, 1920 x 1080 (HD 1080), 3072 x 1728, 3840 x 2160, 640 x 360, 2560 x 1440, 352 x 288, 720 x 576, 1280 x 720 (HD 720)
Maximum resolution: 3840 x 2160 pixels
Bit rate: 128 Kbps~16 Mbps
Video compression formats: M-JPEG, H.265, H.264
Total megapixels: 8 MP
Noise reduction technology: 2D noise reduction, 3D noise reduction
Noise reduction: Yes
Privacy masking: Yes
Highlight Compensation (HLC): Yes
Back Light Compensation (BLC): Yes
Region of Interest (ROI) encoding: Yes
Smart IR: Yes
Night vision
LED type: IR
Night vision distance: 40 m
Infra-red wavelength: 850 nm
Night vision: Yes
Lens system
Lens diameter (wide): 2.8 mm
Observe distance (tele): 149 m
Identify distance (wide): 8.7 m
Focus: Motorized
Detect distance (wide): 86.9 m
Identify distance (tele): 37.2 m
Zoom capability: Yes
Recognize distance (tele): 74.5 m
Focal length range: 2.8 - 12 mm
Auto focus: Yes
Detect distance (tele): 372.4 m
Observe distance (wide): 34.8 m
Recognize distance (wide): 17.4 m
Lens diameter (tele): 1.2 cm
