Features UPS topology: Line-Interactive Input frequency: 50/60 Hz Automatic Voltage Regulation (AVR): Yes Output frequency: 50/60 Hz Output operation voltage (min): 191 V Input operation voltage (min): 162 V Power protection features: Overload, Short circuit Input operation voltage (max): 290 V Audible alarm(s): Yes Waveform: Sine Surge protection: Yes Output power capacity: 0.35 kVA Number of input phases: 1 Audible alarm modes: Fault, Low battery alarm, Overload alarm Number of output phases: 1 Output operation voltage (max): 253 V Output power: 245 W
Design International Protection (IP) code: IP20 Product colour: Black Form factor: Tower
Operational conditions Operating relative humidity (H-H): 20 - 80% Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): 0 - 40 °C Storage relative humidity (H-H): 20 - 95%
Weight & dimensions Height: 158 mm Width: 84 mm Depth: 286 mm Package height: 225 mm Package width: 122 mm Weight: 3.8 kg
Ports & interfaces AC outlet types: C13 coupler AC outlets quantity: 2 AC outlet(s)
Battery Battery voltage: 12 V Cold start: Yes Number of batteries supported: 1 Battery capacity: 5 Ah Battery technology: Sealed Lead Acid (VRLA)
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock.
