Design
Gallium nitride (GaN) transistors: Yes
Plug and Play: Yes
Housing material: Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC)
Product colour: Grey, Black
Power
Port 4 output power: 18 W
Port 3 output power: 20 W
Port 2 output power: 140 W
Port 1 output power: 140 W
Output current (20V): 5 A
Output current (9V): 3 A
Port 4 output current: 3 A
Output current (15V): 3 A
Maximum output voltage: 20 V
Input frequency: 50/60 Hz
Port 1 output current: 5 A
Output current (5V): 3 A
Input voltage: 100 - 240 V
Maximum power: 140 W
Port 3 output current: 3 A
Input current: 2.1 A
Compatible power plug types: US, EU, UK
Port 2 output current: 5 A
Output current (12V): 3 A
Minimum output voltage: 3.3 V
Operational conditions
Operating temperature (T-T): -10 - 40 °C
Operating relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -20 - 80 °C
Weight & dimensions
Height: 67.7 mm
Width: 31.3 mm
Depth: 76.5 mm
Weight: 270 g
Performance
Programmable power supply (PPS): Yes
USB Type-C ports quantity: 3
USB Power Delivery (USB PD): Yes
Fast charging: Yes
Power source type: AC
Fast charging technology: Quick Charge 3.0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Charger compatibility: Universal
USB Power Delivery up to: 140 W
Charger type: Indoor
Power protection features: Short circuit, Over voltage, Overheating, Over current
Packaging data
Package weight: 390 g
Package width: 47 mm
Package height: 131.5 mm
Package type: Hanging box
Package depth: 110 mm
Packaging content
Quantity per pack: 1 pc(s)
AC adapter included: Yes
Certificates
Compliance certificates: RoHS, REACH
Logistics data
Customs product code (TARIC): 85366990
Shipping (inner) case height: 13.1 cm
Master (outer) case height: 302 mm
Shipping (inner) case width: 25.5 cm
Master (outer) case length: 305 mm
Shipping (inner) case gross weight: 4.1 kg
Shipping (inner) case length: 28.5 cm
Products per master (outer) case: 20 pc(s)
Products per shipping (inner) case: 10 pc(s)
Master (outer) case width: 280 mm
Master (outer) case gross weight: 8.6 kg
Safety warning
Hazard pictogram(s): GHS07: Harmful
Warnings: Do not open or dismantle the appliance to avoid risk of electric shock., The product must be disposed of in accordance with the regulations for the disposal of electronic equipment., Do not use the product in a humid environment to prevent damage and risk of fire.
Sustainability
Sustainability compliance: Yes
