Technical details
Sustainability compliance: Yes
Compliance certificates: REACH, RoHS
Design
Plug and Play: Yes
Product colour: Black, Grey
Housing material: Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC)
Gallium nitride (GaN) transistors: Yes
Power
Minimum output voltage: 3.3 V
Compatible power plug types: UK, US, EU
Output current (5V): 3 A
Port 3 output current: 5 A
Input current: 2.5 A
Output current (12V): 3 A
Input voltage: 100 - 240 V
Port 2 output current: 5 A
Maximum power: 200 W
Input frequency: 50/60 Hz
Port 1 output current: 5 A
Maximum output voltage: 21 V
Port 2 output power: 100 W
Port 3 output power: 65 W
Port 1 output power: 100 W
Output current (9V): 3 A
Output current (20V): 5 A
Port 4 output power: 60 W
Port 4 output current: 5 A
Output current (15V): 3 A
Operational conditions
Storage temperature (T-T): -20 - 80 °C
Operating relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -10 - 40 °C
Weight & dimensions
Width: 36 mm
Weight: 314 g
Depth: 83.5 mm
Height: 64.8 mm
Performance
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB Power Delivery (USB PD): Yes
Power protection features: Overheating, Over current, Short circuit, Over voltage
Charger type: Indoor
USB Type-C ports quantity: 3
Fast charging technology: Quick Charge 3.0
USB Power Delivery up to: 200 W
Charger compatibility: Universal
Power source type: AC
Fast charging: Yes
Programmable power supply (PPS): Yes
Packaging data
Quantity per pack: 1 pc(s)
Package weight: 430 g
Package type: Hanging box
Package depth: 110 mm
Package height: 131.5 mm
Package width: 47 mm
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Logistics data
Master (outer) case width: 280 mm
Master (outer) case length: 305 mm
Shipping (inner) case height: 13.1 cm
Master (outer) case gross weight: 9.4 kg
Shipping (inner) case gross weight: 4.5 kg
Products per master (outer) case: 20 pc(s)
Shipping (inner) case length: 28.5 cm
Products per shipping (inner) case: 10 pc(s)
Master (outer) case height: 302 mm
Shipping (inner) case width: 25.5 cm
Customs product code (TARIC): 85366990
Safety warning
Hazard pictogram(s): GHS07: Harmful
