Features Power protection features: Under voltage, Over voltage, Over power, Overheating, Overvoltage protection Purpose: Solar panel International Protection (IP) code: IP22 Brand compatibility: Victron Energy Efficiency: 96% Power current type: DC/AC
Design Built-in display: No Material: Steel Product colour: Blue Built-in fan: Yes Number of VE.Bus ports: 2
Power Peak power: 18000 W AC input voltage: 187 - 265 V DC input voltage: 48 V Input voltage: 38 - 66 V Frequency range: 45 - 65 Hz Output voltage: 230 V Apparent power: 10000 VA Frequency: 50 Hz Output power at 25°C: 8000 W Charging the current battery: 140 A Charging voltage (absorption) : 57.6 V Charging voltage (liquid): 55.2 V Power at zero load: 38 W Output power at 65°C : 6000 W Output power at 40°C : 7000 W
Operational conditions Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): -40 - 65 °C
Weight & dimensions Depth: 206 mm Weight: 49 kg Height: 677 mm Width: 363 mm
