Features Efficiency: 95% Power protection features: Overheating, Overvoltage protection, Under voltage, Over voltage, Over power Brand compatibility: Victron Energy Purpose: Solar panel Power current type: AC/AC
Design Built-in display: No Material: Steel International Protection (IP) code: IP22 Product colour: Blue Built-in fan: Yes Number of VE.Bus ports: 2 LED indicators: Yes
Power Peak power: 27000 W Output voltage: 230 V Charging voltage (liquid): 55.2 V DC output voltage: 48 V Frequency range: 45 - 65 Hz Output power at 40°C : 10000 W Input voltage: 38 - 66 V Output power at 65°C : 7000 W Frequency: 50 Hz Charging voltage (absorption) : 57.6 V Power at zero load: 55 W Apparent power: 15000 VA AC input voltage: 187 - 265 V Output power at 25°C: 12000 W Charging the current battery: 200 A
Weight & dimensions Height: 810 mm Width: 405 mm Depth: 217 mm Weight: 80 kg
