Technical details
OPS slot: 1
Design
Screen shape: Flat
Product design: Digital signage flat panel
Product colour: Black
VESA mounting: Yes
Placement supported: Indoor
Panel mounting interface: 400 x 200
Mounting type: Wall
Bezel width (top): 1.5 cm
Anti-glare screen: Yes
Orientation: Horizontal/Vertical
Bezel width (bottom): 1.5 cm
Bezel width (side): 1.5 cm
Power
AC input frequency: 50 - 60 Hz
Power consumption (typical): 155 W
AC input voltage: 100 - 240 V
Power consumption (max): 250 W
Power consumption (standby): 0.5 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Weight: 13.4 kg
Display weight: 13.4 kg
Display height: 703.5 mm
Display width: 1233 mm
Display depth: 71.5 mm
Performance
Purpose: Universal
HDCP: Yes
Operating hours (hours/days): 24/7
HDCP version: 2.2
Packaging data
Package width: 1332 mm
Package height: 819 mm
Package weight: 19.5 kg
Package depth: 156 mm
Packaging content
Cables included: AC, RS-232, USB Type-C, HDMI
Mounting kit: Yes
Batteries included: Yes
Remote control included: Yes
Display
Display number of colours: 1.07 billion colours
Native aspect ratio: 16:9
Contrast ratio (dynamic): 5000:1
Touchscreen: No
Viewing angle, vertical: 178°
Viewing angle, horizontal: 178°
Response time: 8 ms
Display diagonal: 139.7 cm (55")
Display resolution: 3840 x 2160 pixels
HD type: 4K Ultra HD
Display technology: LCD
Display brightness: 450 cd/m²
Haze rate: 25%
Surface hardness: 3H
Contrast ratio (typical): 1200:1
LED backlighting type: Direct-LED
Display diagonal (metric): 139 cm
Panel type: ADS
Native refresh rate: 60 Hz
Panel life: 50000 h
Audio
RMS rated power: 20 W
Built-in speaker(s): Yes
Number of built-in speakers: 2
Ports & interfaces
HDMI ports quantity: 3
Ethernet LAN data rates: 10, 100, 1000
USB port: Yes
DVI port: No
USB connector type: USB Type-A, USB Type-C
HDMI version: 2.1
RS-232 interface: Yes
Wi-Fi: No
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN: Yes
HDMI output ports quantity: 1
OPS module slot: Yes
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
HDMI input ports quantity: 2
USB ports quantity: 3
Other features
Quick start guide: Yes
Logistics data
Products per master (outer) case: 1 pc(s)
Harmonized System (HS) code: 8528521000
Pallet gross width: 145 cm
Pallet gross length: 114 cm
Pallet gross height: 94.5 cm
Computer system
Internal memory: 4 GB
Processor model: Amlogic T982
Operating system installed: Android 11
Built-in processor: Yes
On-board graphics card model: ARM Mali-G52
Processor cores: 4
Processor frequency: 1.9 GHz
Internal storage capacity: 32 GB
Computer system type: System on Chip (SoC)
Computer system: Yes
