Technical details
Image lag time: 163 ms
Features
Number of OSD languages: 24
Interactive: No
HDCP: Yes
Noise level: 40 dB
On Screen Display (OSD) languages: English, Simplified Chinese, Arabic, Traditional Chinese, French, Korean, Romanian, Japanese, Swedish, Polish, Finnish, Turkish, German, Czech
On Screen Display (OSD): Yes
Design
Product colour: Blue, Black
Product type: Projector module
Market positioning: Home cinema
Power
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power source: AC
Power consumption (typical): 144 W
Power consumption (standby): 0.5 W
Operational conditions
Operating temperature (T-T): 0 - 35 °C
Weight & dimensions
Weight: 3.13 kg
Package depth: 232 mm
Package width: 315 mm
Package weight: 4.3 kg
Package height: 323 mm
Width: 228 mm
Height: 159 mm
Depth: 227 mm
Network
Smart TV: Yes
Bluetooth version: 5.0
Bluetooth: Yes
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Ethernet LAN: No
Packaging content
Remote control type: Bluetooth
Cables included: Power
Manual: Yes
Remote control included: Yes
Display
Built-in display: No
Multimedia
Built-in speaker(s): Yes
Number of built-in speakers: 2
RMS rated power: 10 W
Storage
Internal storage capacity: 8 GB
Card reader integrated: No
Ports & interfaces
USB 2.0 Type-A ports quantity: 2
Audio (L/R) out: 1
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
HDMI version: 1.4
Video
Full HD: Yes
Supported video modes: 1080i, 576p, 720p, 576i, 480i, 480p, 1080p
Lens system
Zoom type: Auto
Offset: 0%
F-number (relative aperture): 2.9
Throw ratio: 1.2
Zoom ratio: 0.8-1:1
Zoom capability: Yes
Focus: Auto
Fixed focal length: 125 mm
Safety warning
Warnings: Avoid placing the projector in high humidity areas to prevent damage to the unit., Do not look directly into the lens of the projector during operation to avoid damage to your eyes., Be careful when replacing the projector lamp as it can be very hot.
Projector
Projector brightness: 630 ANSI lumens
Keystone correction, horizontal: -40 - 40°
Projector native resolution: 1080p (1920x1080)
Projection distance: 1.42 - 3.8 m
Horizontal scan range: 15 - 135 kHz
Projection technology: LCD
Number of colours: 16.7 million colours
Keystone correction, vertical: - 40 -40°
Screen size compatibility: 1270 - 3556 mm (50 - 140")
Vertical scan range: 23 - 85 Hz
Smart projector: Yes
Contrast ratio (typical): 4200:1
Light source
Light source type: LED
Service life of light source: 20000 h
Light source brightness: 630 lm
