Technical details
Image lag time: 33.2 ms
Features
On Screen Display (OSD): Yes
Noise level: 34 dB
HDCP: Yes
Noise level (economic mode): 25 dB
HDCP version: 1.4
Air filter: Yes
Interactive: No
On Screen Display (OSD) languages: Simplified Chinese, Thai, Arabic, Russian, Czech, German, Italian, Dutch, English, Spanish, Traditional Chinese, French, Finnish, Turkish, Portuguese, Polish, Indonesian, Vietnamese, Hungarian, Korean, Greek
Number of OSD languages: 22
Design
Product colour: White
LED indicators: Yes
Product type: Standard throw projector
Cable lock slot: Yes
Cable lock slot type: Kensington
Market positioning: Education
Power
AC input voltage: 100 - 240 V
Power consumption (typical): 295 W
Power source: AC
AC input frequency: 50 - 60 Hz
Power consumption (standby): 0.5 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Package depth: 168 mm
Height: 115 mm
Package weight: 3.8 kg
Package width: 400 mm
Weight: 2.7 kg
Depth: 234 mm
Width: 309 mm
Package height: 337 mm
Network
Wi-Fi: No
Ethernet LAN: No
Smart TV: No
Packaging content
Cables included: VGA, AC
Quick start guide: Yes
Warranty card: Yes
Remote control included: Yes
Remote control type: IR
Display
Built-in display: No
Multimedia
Built-in speaker(s): Yes
Number of built-in speakers: 1
RMS rated power: 3 W
Storage
Card reader integrated: No
Ports & interfaces
USB 2.0 ports quantity: 1
DVI port: No
HDMI ports quantity: 2
HDMI version: 1.4
VGA (D-Sub) ports quantity: 2
Service port type: USB Type-A
USB 2.0 Type-A ports quantity: 1
Serial interface type: RS-232
PC Audio out: Yes
HDMI connector type: Full-size
PC in (D-Sub): Yes
PC Audio in: Yes
AC (power) in: Yes
Logistics data
Pallet gross length: 102 cm
Products per master (outer) case: 1 pc(s)
Pallet gross width: 122 cm
Harmonized System (HS) code: 8528620000
Pallet gross height: 184.5 cm
Video
Supported graphics resolutions: 640 x 480 (VGA), 1920 x 1080 (HD 1080)
Full HD: Yes
3D: No
Supported video modes: 720p, 576i, 480p, 1080p, 1080i, 480i, 576p
Analog signal format system: NTSC, PAL, SECAM
Lens system
Zoom capability: Yes
Offset: 115%
Throw ratio: 1.94 - 2.16
Aperture range (F-F): 2.42 - 2.53
Optical zoom: 1.1x
Digital zoom: 2x
Focal length range: 21.85 - 24.01 mm
Focus: Manual
Projector
Vertical scan range: 23 - 120 Hz
Horizontal scan range: 15 - 102 kHz
Smart projector: No
Projector brightness: 4500 ANSI lumens
Projection distance: 1.18 - 13.17 m
Number of colours: 1.07 billion colours
Projector native resolution: SVGA (800x600)
Keystone correction, vertical: -40 - 40°
Screen size compatibility: 762 - 7620 mm (30 - 300")
Contrast ratio (typical): 12500:1
Light source
Lamp power: 240 W
Service life of light source: 4000 h
Lamps quantity: 1 lamp(s)
Light source type: Lamp
Service life of light source (economic mode): 12000 h
Lamp type: UHP
