Features
HDCP: Yes
Noise level: 34 dB
On Screen Display (OSD) languages: Spanish, Swedish, Turkish, Vietnamese, Simplified Chinese, Japanese, Russian, Czech, Finnish, Arabic, Portuguese, Thai, English, Polish, Indonesian, German, Italian, Dutch, Traditional Chinese, French, Korean, Greek
On Screen Display (OSD): Yes
Noise level (economic mode): 25 dB
Number of OSD languages: 20
Interactive: No
Design
Product colour: White
Product type: Standard throw projector
Placement: Desktop, Ceiling
Market positioning: Presentation
Power
AC input voltage: 100-240 V
AC input frequency: 50 - 60 Hz
Power source: AC
Power consumption (typical): 310 W
Power consumption (standby): 0.5 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Package width: 400 mm
Package weight: 3.8 kg
Package depth: 168 mm
Weight: 2.7 kg
Height: 115 mm
Width: 309 mm
Depth: 234 mm
Package height: 337 mm
Network
Wi-Fi: No
Smart TV: No
Packaging content
Cables included: VGA, AC
Manual: Yes
Remote control included: Yes
Display
Built-in display: No
Multimedia
Built-in speaker(s): Yes
RMS rated power: 5 W
Storage
Card reader integrated: No
Ports & interfaces
USB 2.0 ports quantity: 1
HDMI ports quantity: 2
DVI port: No
HDMI version: 1.4
Serial interface type: RS-232
PC Audio out: Yes
Composite video in: 1
AC (power) in: Yes
HDMI connector type: Full-size
PC Audio in: Yes
Logistics data
Products per master (outer) case: 1 pc(s)
Pallet gross length: 102 cm
Harmonized System (HS) code: 8528620000
Pallet gross width: 122 cm
Pallet gross height: 181.5 cm
Video
Full HD: Yes
Supported graphics resolutions: 640 x 480 (VGA), 1920 x 1200 (WUXGA)
Analog signal format system: NTSC, PAL, SECAM
Supported video modes: 1080i, 480p, 1080p, 576i, 720p, 576p, 480i
Lens system
Focal length range: 10.2 - 12.24 mm
Focus: Manual
Zoom capability: Yes
Offset: 105%
Zoom ratio: 2.0:1
Throw ratio: 1.48-1.62
Aperture range (F-F): 2.6 - 2.78
Projector
Horizontal scan range: 15 - 102 kHz
Contrast ratio (typical): 22000:1
Vertical scan range: 23 - 120 Hz
Screen size compatibility: 762 - 7620 mm (30 - 300")
Projector native resolution: 1080p (1920x1080)
Keystone correction, horizontal: -40 - 40°
Keystone correction, vertical: -40 - 40°
Projection technology: DMD
Projection distance: 0.9 - 2.2 m
Number of colours: 1.07 billion colours
Matrix size: 1.65 cm (0.65")
Projector brightness: 4000 ANSI lumens
Light source
Lamp power: 240 W
Light source type: Lamp
Service life of light source: 4000 h
Service life of light source (economic mode): 15000 h
Lamps quantity: 1 lamp(s)
