Features
M.2 SSD size: 2280 (22 x 80 mm)
Mean time between failures (MTBF): 1750000 h
Read speed: 6600 MB/s
Hardware encryption: Yes
PCI Express interface data lanes: x4
Component for: PC/Laptop
Security algorithms: TCG Pyrite
NVMe: Yes
Write speed: 5600 MB/s
SSD capacity: 500 GB
Random read (4KB): 660000 IOPS
SSD form factor: M.2
TBW rating: 300
Interface: PCI Express 4.0
Memory type: QLC 3D NAND
Random write (4KB): 1100000 IOPS
Power
Average power consumption (read): 3.8 W
Average power consumption (write): 3.8 W
Operational conditions
Operating vibration: 5 G
Operating shock: 1500 G
Operating temperature (T-T): 0 - 85 °C
Non-operating vibration: 4.9 G
Storage temperature (T-T): -40 - 85 °C
Weight & dimensions
Weight: 5.7 g
Height: 2.38 mm
Depth: 80 mm
Width: 22 mm
Packaging data
Package weight: 49 g
Package width: 101.6 mm
Package type: Box
Package height: 126 mm
Package depth: 21 mm
Other features
Compliance certificates: KCC, UL, BSMI, UKCA, Federal Communications Commission (FCC), ICES, VCCI, RoHS, CE, RCM, CB
