Design
Product colour: Black
Fan connector: 4-pin
Fins material: Aluminium
Base plate material: Copper
Number of heat pipes: 5
Number of fans: 2 fan(s)
Power
Rated voltage: 12 V
Thermal Design Power (TDP): 220 W
Weight & dimensions
Weight: 685 g
Package weight: 900 g
Depth: 128 mm
Height: 150 mm
Width: 108 mm
Fan 2 dimensions (W x D x H): 120 x 120 x 25 mm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Performance
Type: Air cooler
Supported processor sockets: LGA 1851, LGA 1151 (Socket H4), LGA 1156 (Socket H), LGA 1700, LGA 1200 (Socket H5), LGA 2011 (Socket R), Socket AM4, LGA 1155 (Socket H2), LGA 1150 (Socket H3), Socket AM5, LGA 2066, LGA 1954
Quantity per pack: 1 pc(s)
Noise level (high speed): 32.5 dB
Bearing type: Fluid Dynamic Bearing (FDB)
Pulse-width modulation (PWM) support: Yes
Noise level (low speed): 18 dB
Suitable location: Processor
Rotational speed (min): 700 RPM
Rotational speed (max): 1600 RPM
Fan diameter: 12 cm
Safety warning
Warnings: Do not touch the fan during operation., Ensure that the unit is switched off before starting to assemble or dismantle the cooling unit., Take appropriate precautions during installation to avoid damage to computer components.
