Design Product colour: Black On/off switch: Yes Cooling type: Active Fan diameter: 12 cm Fan location: Top Number of fans: 1 fan(s)
Power Max output current (+3.3V): 21 A AC input frequency: 50 Hz Combined power (+12V): 456 W Power Factor Correction (PFC) type: Active Combined power (+3.3V): 105 W Input current: 10 A Power protection features: Under voltage, Over power, Short circuit, Over voltage Total power: 550 W AC input voltage: 200 - 240 V Max output current (+5Vsb): 2.5 A Max output current (+5V): 16 A Max output current (+12V): 38 A Max output current (-12V): 0.5 A
Performance Bearing technology: FDB Purpose: PC Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Bronze ATX version: 2.4
Packaging data Package weight: 1.89 kg Package type: Box
Certificates Compliance certificates: WEEE, RoHS
Ports & interfaces Floppy disk drive connector: Yes ATX power connector (20+4 pin): Yes Floppy drive power connector: 1 Peripheral (Molex) power connectors (4-pin): 3 PCI Express power connectors (6+2 pin): 2 Motherboard power connector: 20+4 pin ATX Number of SATA power connectors: 6 PCI Express connector: Yes CPU power connector (4+4 pin): Yes Motherboard power cable length: 50 cm Cabling type: Non-Modular
