Design
On/off switch: Yes
Fan location: Top
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Cooling type: Active
Product colour: Black
Power
Power protection features: Overheating, Short circuit, Over voltage, Under voltage, Over power
AC input frequency: 50 - 60 Hz
Combined power (+5V): 100 W
Total power: 850 W
Power Factor Correction (PFC) type: Active
Combined power (-12V): 3.6 W
Combined power (+3.3V): 66 W
AC input voltage: 200 - 240 V
Input current: 6.3 A
Combined power (+5Vsb): 16 W
Weight & dimensions
Depth: 247 mm
Height: 98 mm
Weight: 2.3 kg
Width: 198 mm
Performance
Bearing technology: HDB
ATX version: 2.52
Power supply unit (PSU) form factor: ATX
Purpose: PC
Silent mode: Yes
80 PLUS certification: 80 PLUS Gold
Ports & interfaces
CPU power connector (4+4 pin): Yes
ATX power connector (20+4 pin): Yes
CPU P4 connector (4-pin): 1
Motherboard power connector: 20+4 pin ATX
Cabling type: Non-Modular
Number of SATA power connectors: 6
PCI Express power connectors (6+2 pin): 3
PCI Express connector: Yes
Motherboard power cable length: 5.5 cm
Safety warning
Hazard pictogram(s): GHS02: Flammable, GHS07: Harmful, GHS09: Environmental hazard
Warnings: Avoid contact of the product with water or other liquids., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations., Do not open the case - risk of electric shock.
