Technical details
Sustainability compliance: Yes
Sustainability certificates: ErP
Design
Product colour: Red, Black
Cooling type: Active
Fan diameter: 14 cm
Number of fans: 1 fan(s)
Power
Efficiency: 85%
AC input frequency: 50 Hz
Max output current (+3.3V): 23 A
Combined power (-12V): 6 W
Max output current (+5Vsb): 2.5 A
Power Factor Correction (PFC) type: Active
Combined power (+5Vsb): 12.5 W
AC input voltage: 200 - 240 V
Input current: 10 A
Max output current (+5V): 17 A
Power protection features: Overheating, Under voltage, Over current, Overload, Over voltage
Max output current (+12V1): 48 A
Total power: 650 W
Combined power (+12V): 576 W
Max output current (-12V): 0.5 A
Performance
Power supply unit (PSU) form factor: ATX
Noise level: 29 dB
Purpose: PC
80 PLUS certification: 80 PLUS Bronze
ATX version: 2.4
Packaging data
Package depth: 440 mm
Package width: 580 mm
Package height: 265 mm
Package weight: 1.98 kg
Certification: ErP2014
Certificates
Compliance certificates: WEEE, REACH, CB, RoHS, CE, cTUVus
Ports & interfaces
Floppy drive power connector: 1
Floppy disk drive connector: Yes
Motherboard power cable length: 50 cm
PCI Express power connectors (6+2 pin): 2
Number of SATA power connectors: 6
Motherboard power connector: 20+4 pin ATX
CPU power connector (4+4 pin): Yes
Number of PATA power connectors: 3
Cabling type: Non-Modular
