Design Fan diameter: 14 cm Number of fans: 1 fan(s) Cooling type: Active Product colour: Black, Red
Power Max output current (+5Vsb): 3 A Power protection features: Short circuit, Over voltage, Over power, Under voltage, Over current Total power: 1250 W AC input frequency: 50/60 Hz Max output current (+3.3V): 20 A Max output current (+12V): 104.1 A Power Factor Correction (PFC) type: Active AC input voltage: 100 - 240 V Input current: 15 A Efficiency: 89% Max output current (-12V): 0.3 A Max output current (+5V): 20 A
Weight & dimensions Depth: 180 mm Width: 150 mm Height: 86 mm
Performance 80 PLUS certification: 80 PLUS Gold Bearing technology: FDB Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 3.0
Packaging data Package type: Box
Certificates Compliance certificates: RoHS, WEEE
Ports & interfaces PCI Express power connectors (6+2 pin): 3 Cabling type: Fully-Modular Number of SATA power connectors: 12 PCI Express power connectors (8-pin): 1 Motherboard power cable length: 65 cm CPU power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX
