Technical details
Warranty period: 2 year(s)
Design
Fan connector: 4-pin
Number of heat pipes: 4
Number of fans: 1 fan(s)
Illumination colour: Multi
Product colour: Black
Illumination LED: Yes
LED connector type: 3-pin
Number of fan blades: 9
Power
Thermal Design Power (TDP): 220 W
LED voltage: 5 V
Fan power consumption: 3 W
Weight & dimensions
Depth: 126 mm
Height: 160 mm
Width: 120 mm
Weight: 1.4 kg
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Performance
Supported processor sockets: LGA 1851, LGA 1156 (Socket H), LGA 1700, Socket AM4, LGA 1150 (Socket H3), Socket AM5, LGA 1155 (Socket H2), Socket AM3, LGA 1200 (Socket H5), LGA 1151 (Socket H4)
Fan diameter: 12 cm
Maximum airflow: 63.62 cfm
Fan speed (min): 800 RPM
Pulse-width modulation (PWM) support: Yes
Bearing type: Fluid Dynamic Bearing (FDB)
Type: Air cooler
Fan noise level (max): 21.19 dB
Mean time between failures (MTBF): 70000 h
Fan static pressure: 1.39 mmH2O
Fan speed (max): 1800 RPM
Suitable location: Processor
